Aicon Scan XR 600 FA X-ray System


X-ray inspection system for fat content measurement in meat

Why Choose the Aicon Scan XR 600 FA X-ray System

icon fat analysis precision
Thanks to Photon Counting (PCT™) and dual-energy imaging technology, the Aicon Scan XR 600 FA determines real-time fat percentage in meat with high accuracy, enabling recipe optimization, batch balancing, and consistent product quality.

icon foreign body detection
In addition to fat content measurement, the system performs X-ray detection of foreign bodies such as metal, glass, calcified bones, stones, and dense plastics, ensuring food safety and reducing the risk of product recalls or customer complaints.

icon system connectivity
Aicon Scan XR 600 FA integrates seamlessly with production and quality management systems (MES, ERP, OPC UA, PROFINET), automatically storing inspection and analysis data. This ensures complete process traceability and continuous monitoring of production performance.

Technical Information

Performance Loose meat: 60 tons/hour, E2 boxes: 2,500 pcs/hour
Speed 600 mm at belt level | Loose meat layer width: 500 mm | E2 box width: 450 mm
Detector resolution 0.7 mm photon-counting detector (Aicon PCT™)
X-ray generator 35–160 kV / 7.0–8.0 mA, max. 500 W
Scan beam Vertical
Beam geometry beam geometry x-ray aicon scan xr 600 fa
X-ray emission 7 µSv/h, product complies with EU regulatory requirements
Cooling method Dry air cooling system / Water cooling
Operating environment Temperature: 0–45°C, humidity: 30–95% non-condensing
Protection class IP69K
Frame material Bead-blasted stainless steel 1.4407 (AISI 316)
Operating system Windows 10 Enterprise
Software AiSoft
Product program memory 500 GB, expandable
Communication interfaces Ethernet card 10/100/1000 Mbps, USB 3.0
Power supply Single phase, 230 VAC ±10%, protection 16 A
Dimensions 1650 mm x 1273 mm x 2735 mm (L x W x H)

technical specifications dimensions aicon scan xr 600 fa
