Aicon Poultry X-ray System


High-performance X-ray system for raw meat and poultry quality control

Why Choose the Aicon Poultry X-ray System

icon ergonomic designSmart and ergonomic design
Ergonomic design choices simplify day-to-day operation and allow fast adjustment and replacement of wear parts. The hygienic construction is optimised for easy cleaning and maintenance, a key requirement for companies processing poultry products.

icon intuitive user interfaceSimple and user-friendly
The user interface is designed for intuitive operation. Product auto-learning functions support operators when configuring inspection recipes, reducing setup time and format changeover.

icon complete mes integrationFull MES integration
The Aicon Poultry X-ray inspection system for poultry products integrates seamlessly into the production environment, thanks to compatibility with major industrial communication standards: Ethernet/IP, PROFINET, S7, EtherCAT, Modbus-TCP, Profibus, CAN, CANopen, OPC UA, SQL, standard Siemens protocols, and RS.

Technical Information

Speed ≤ 60 m/min
Detection field 450 mm / 500 mm
Overall dimensions 2650 mm x 1415 mm x 2600 mm (L x W x H)
Display 17″ TFT LCD touchscreen
Detector resolution 0.1 mm photon-counting detector (Aicon PCT™)
X-ray generator 35-160 kV / 1.0-8.0 mA, max. 500 W
Number of scan beams 1
Beam direction Vertical
Beam geometry beam geometry aicon poultry
X-ray emission µSv/h, the product complies with EU regulatory requirements
Operating environment Temperature: 0 – 45°C, humidity: 30 – 95% non-condensing
Cooling method Dry air cooling system / water cooling
Protection class IP69K
Frame material Bead-blasted stainless steel 1.4301 (AISI 304)
Operating system Windows 10 Enterprise
Software AiSoft
Product program memory 1000
Disk space 500 GB, expandable
Communication interfaces Ethernet card 10/100/1000 Mbps, USB 3.0
Air supply Min. 6 bar for pneumatic ejectors
Power supply Single phase 230 VAC ±10%, protection 16 A

aicon poultry technical specifications
